SINGLE STAGE NITROGEN REGULATOR WITH TUBE

SINGLE STAGE NITROGEN REGULATOR WITH TUBE Specification

Storage Instructions
Store in a Dry, Clean Environment Avoiding Direct Sunlight

Shelf Life
Long Shelf Life (Mechanical Hardware)

Instruments Type
Gas Pressure Regulator

Accuracy
2% of Full Scale

Display Type
Analog Pressure Gauge

Features
High Precision, Corrosion Resistant, Easy To Install, Clear Pressure Gauge, Leak-Proof Design

Function
Pressure Reduction and Regulation of Nitrogen Supply

Measurement Range
0 to 3000 PSI (primary gauge), 0 to 100 PSI (secondary gauge)

Usage Type
Industrial/Laboratory

Equipment Type
Single Stage Nitrogen Regulator with Tube

Material
Brass Body with Stainless Steel Diaphragm

Condition
New

Technology
Conventional Mechanical Pressure Regulation

Portable
Yes

Wall Mounted
No

Real-Time Operation
Yes

Noise Level
Silent Operation

Operating Type
Manual

Use
Regulating Nitrogen Gas Pressure in Industrial or Laboratory Applications

Power Source
Not Required (Mechanical)

Dimension (L*W*H)
Approx. 17 cm x 12 cm x 13 cm

Weight
Approx. 1.2 kg

Color
Golden with Black and Red Accents

Number of Gauges
Two (Inlet & Outlet)

Outlet Connection
Tube with Hose Nipple (Supplied)

Diaphragm Material
Stainless Steel

Application Compatible Gas
Nitrogen Only

Regulator Stage
Single Stage

Mounting
Cylinder Mounted

Leakage Test
100% Factory Leak-Tested

Working Temperature Range
-10C to 60C

Maximum Outlet Pressure
100 PSI

Connection Inlet Size
1/4" BSP or As Specified

Maximum Inlet Pressure
3000 PSI

About SINGLE STAGE NITROGEN REGULATOR WITH TUBE

Product Size Product Code

Standard MSI-1229

Safety Gauge 3500 kg/cm2 for Inlet Pressure

Pre Set Locked Nut

Built in Safety Valve

Brass Chrome Plated Body

Usage : Connect with Central N Pipeline 2

Packing : Paper BoX

High Precision Nitrogen Pressure Regulation

Engineered for efficiency, the Single Stage Nitrogen Regulator offers accurate pressure control from cylinders to instruments or processes. Its sturdy brass body and stainless steel diaphragm provide long-term durability and resistance to corrosion, making it ideal for demanding settings. The clear analog gauges display both inlet and outlet pressures, ensuring easy and safe adjustments for various industrial or laboratory applications.

Easy Installation and Reliable Operation

Designed for quick cylinder mounting, this regulator comes with an included tube and hose nipple for straightforward setup. The regulator is factory leak-tested for safety and is completely mechanical in operation, requiring no external power. Thanks to its portable design and silent operation, it delivers consistent results wherever you need safe nitrogen pressure management.

FAQ's of SINGLE STAGE NITROGEN REGULATOR WITH TUBE:

Q: How do I install the Single Stage Nitrogen Regulator with Tube onto a nitrogen cylinder?

A: Installation is simple: secure the regulator to the cylinder's outlet using the 1/4" BSP or specified inlet connection. Attach the supplied hose nipple and tube to the outlet. Ensure all connections are tight, check the gauges, and perform a brief leak check before use.

Q: What types of applications is this nitrogen regulator suitable for?

A: This regulator is specifically designed for industrial and laboratory applications where precise nitrogen pressure control is needed, such as analytical instrumentation, material testing, or manufacturing processes requiring inert atmospheres.

Q: When should I use a single stage nitrogen regulator instead of a dual stage regulator?

A: Single stage regulators are ideal for applications where inlet pressure won't vary greatly or where downstream pressure can tolerate minor fluctuations. For short or consistent use situations, this model provides reliable and accurate performance.

Q: Where is the best place to store the regulator when not in use?

A: Store the regulator in a dry, clean area away from direct sunlight to preserve its components and ensure a long service life. Proper storage helps prevent corrosion and maintains accuracy.

Q: What is the process for pressure adjustment and gauge monitoring?

A: After installation, slowly open the cylinder valve and use the manual adjustment knob to set the desired outlet pressure, referring to the analog pressure gauges for precise readings. Always monitor both inlet and outlet pressures during use.

Q: How does the regulator ensure user safety and performance reliability?

A: The regulator is 100% factory leak-tested for safety and features a stainless steel diaphragm and robust brass body for durability and corrosion resistance. Clear analog gauges provide real-time monitoring, and its leak-proof design further assures safe operation.
